Feature:
1. 4800KV brushless 4 pole high?torque motor design, CNC processed 6061 T6 aluminum billet heat sink tank.
2. Programming card has 4 buttons, ITEM, VALUE, OK, RESET button, with indicator light, easy to set.
3. High?purity copper windings can maximize efficiency and have strong anti?interference ability.
4. Precisely balanced rotor, best smoothness, reliability and maximum RPM, fast response to throttle input.
5. There are multiple protection functions, low voltage cut?off protection, overheat protection, and throttle signal loss protection.
Specification:
Item Type: 2435 4800KV Motor Set
Material: Aluminum Alloy + Copper + Plastic
Weight: Approx.148g5.3oz
Motor Parameters:
Color: Black
Motor Size:
Diameter: Approx. 24mm0.9in
Length: Approx. 35mm1.4in
Shaft Diameter: Approx. 2mm0.1in
Shaft Length: Approx. 12mm0.5in
Motor Head Connector: Approx. 3.5mm0.1in
KV: 4800KV
Maximum Current: 24A
Maximum Wattage: 300W
Maximum Voltage: 7.4V(2S)11.1V(3S)
ESC Parameters:
Continuous Current: 35A
Maximum Current: 120A
Product Applicable Battery: 23S Lithium Battery69S Nickel Metal Hydride Battery (not Included)
BEC Output: 5.8V3A
Power Plug: T Male
Motor Plug: 3.5mm0.1in
Programming Card Parameters:
Low Voltage Cutoff: 3.7V 3.6V 3.5V 3.4V 3.3V 3.2V 3.1V 3.0V 2.9V 2.8V 2.7V 2.6V
Startup Mode: MediumSoftStrong
Maximum Braking Force: 50percent ,25percent ,75percent ,100percent (25A,35A,45A,60A)
25percent , 50percent , 75percent , 100percent (80A, 120A)
Maximum Reverse Force: 25percent , 50percent , 75percent , 100percent
Neutral Range: 9percent , 6percent , 12percent Working Status
Application: for 116 118 Remote Control Car.
Package List:
1 x Motor 1 x ESC1 x Programming Card1 x Manual4800KV brushless 4 pole high?torque motor design, CNC processed 6061 T6 aluminum billet heat sink tank.
Programming card has 4 buttons, ITEM, VALUE, OK, RESET button, with indicator light, easy to set.
High?purity copper windings can maximize efficiency and have strong anti?interference ability.
Precisely balanced rotor, best smoothness, reliability and maximum RPM, fast response to throttle input.
There are multiple protection functions, low voltage cut?off protection, overheat protection, and throttle signal loss protection.
