Feature:
1. Digital video microscope camera kit, using 51MP for MOSS sensor 1 2.33in, with high‑definition multimedia interface USB2.0 dual output camera.
2. High resolution, good flatness and contrast, can provide clear images, and facilitate the observation of the internal structure of small objects.
3. Adjustable 144LED ring light, providing dense and concentrated shadowless lighting, lighting direction can be changed, variable strength control, 100,000 hours of life.
4. This microscope is very suitable for gemologists, manufacturing engineers, laboratories, technicians and anyone in the electronics and semiconductor industries.
5. Equipped with a fine‑tuner, better focusing and use, support for Windows XP 7 8 10 system, easy to install, convenient to observe.
Specification:
Item Type: Microscope Camera Set
Material: Aluminum Alloy, Alloy
Purpose: Very suitable for gemologists, manufacturing engineers, laboratories, technicians and anyone in the electronics and semiconductor industries
Remote Control Battery Type: 1 x CR2025 Button Battery (Battery Not Included)
Camera Model: HY 1139
Type: HD Multimedia Interface USB2.0 Dual Output Camera
Picture Format: Jpg
Image Resolution: 51MP
Video Format: MP4 (For Memory Card)
Video Recording: 1080P 60FPS
High Definition Multimedia Interface Video Resolution: 1920x1080 60FPS (For HD Multimedia Interface)
USB Video Resolution: 1920x1080 30FPS; 1280x720 30FPS; 640x480 30FPS; 320x240 30FPS
White Balance: Automatic Manual
Light: Automatic Manual
Exposure: Automatic Manual, Value can be adjusted
Direction: Left Right, Up Down
Freeze: Support
OSD: English Chinese French Spanish Japanese German
Lines: Different colors, 5 horizontal lines, 5 vertical lines, any position
Image Sensor: 51MP for MOSS sensor 1 2.33 inch
Effective Pixels: 51MP
Pixels Size: 1.335micrometerx1.335micrometer
Frame Rate: 60fps
Picture Definition: Full HD
Lens: C CS
Video Format: MOV
Digital Zoom: Support
Brightness Control: Automatic Manual
Color: R G BA Adjustable
Films and Records: Support
Cursor: Support multi color, adjustable size
Horizontal and vertical lines
Support multi color, 5 horizontal vertical lines, movable
Different colors, 5 horizontal lines, 5 vertical lines, any position.
Memory Card Interface: Maximum 64G (Not Included)
High Definition Multimedia Interface: Standard high definition multimedia interface output (Type A)
USB Interface: Standard USB2.0 Interface (Type B)
Input Voltage: DC12V
180X C MOUNT Lens:
Working Distance: Approx. 95mm 3.7in
Zoom Lens: 0.5X C Mount Buckle Adapter
Zoom Ratio: 6.5:1
Objective Lens Magnification: 0.7 4.5X (approximately 10 180X display)
Lens Size: Approx. 180x50mm 7.1x2.0in
LED Light:
Lamp Inner Diameter: Approx. 60mm 2.4in
Total Outer Diameter: Approx. 95mm 3.7in
Working Range: Approx. 27 45mm 1.1 1.8in.
Package List:
1 x Camera1 x Lens1 x Fine Tuner1 x Pillar1 x Base1 x LED Light1 x Clamp1 x Remote Control (Battery Not Included)1 x HD Multimedia Interface Cable1 x USB Cable1 x Software CD2 x Power1 x Hex Wrench1 x Manual
Note:
1. Please allow 0‑1 inch error due to manual measurement. Thanks for your understanding.2. Monitors are not calibrated same, item color displayed in photos may be showing slightly different from the real object. Please take the real one as standard.3. Do not place the product in an environment that is too corrosive, humid and high temperature.4. Please supply power in accordance with the operating voltage, using other voltages may easily cause fire and product damage.
