Ayzeze: Please note that in most European countries the speed limit for electric scooters is 20 km/h.
-----
📊Specifications
Model: KuKirin G2 Master
Packing size: 1280*260*585mm（inner）/1295*272*605mm（outer）
Product G.W: 39.5±0.5kg
Product N.W: 33.5±0.2kg
Expend size: 1260*595*1315mm
Fold size: 1260*595*595mm
Handlebar size: 595mm
Pedal Size: 550*190mm
Pedal to Handlebar size: 1040mm
Chassis height: 162mm
Max Load: 120kg
Maxium speed: 60km/h
1st、2nd、3rd (Single drive): 20km/h、40km/h、55km/h
1st、2nd、3rd (dual drive,65kg load): 20km/h、40km/h、60km/h
1.Please note: All speed figures refer to the maximum values measured under controlled laboratory conditions with a rider weight of 55–65 kg, a fully charged battery, and a flat road surface. Actual riding speed may vary depending on real-world conditions.
2.The product is delivered with a default speed-limited mode, and the corresponding top speeds can only be reached after unlocking the speed restriction.
Middle speed mileage (65kg load): ≤70km
Climbing ability: ≤28° slope
Brake system: Front and rear disc brake&e-brake
Brake distance: 6-12m
Waterproof level: IP54
Frame material: Aluminum alloy
Motor type: Brushless DC hub motor (front and rear wheel dual drive)
Voltage: 52V
Accelerate mode: Sine wave
Rated power: 1000W*2
Instantaneous maximum power: 1200W*2
Rated speed: 1270 rpm
Max output torque: 26 N·m
Battery Model: 18650 Lithoum battery
Battery Voltage: 52V
Single cell capacity: 2600mAh
Battery pack capacity: 20.8Ah
Standard power consumption: 1.0816kW·h
Battery protect system: Battery protective board（BMS）
Input voltage: 100-240VAC~50/60Hz
Input current: 2A Max
Output voltage: 58.8V
Output current: 2A
Charging time: 10-11h
Front shock absorber: Hydraulic shock absorber
Rear shock absorber: Hydraulic shock absorber
Headlight type: LED
Headlight power: 6W
Headlight illumination angle: 45°
Headlight illumination area: 5㎡
Turn light: Yes
Taillight: Yes, The taillights are on when the headlight is on, taillight flash when breaking.
Tire Size: 10in（255*80mm）
Tire Type: Pneumatic tire
Optimum tire pressure: 350kPa(50psi）
Display Type: LCD
Display material: Instrument case ABS/instrument bracket PA6
Display Size: 133*76mm
Show content: Light indication, cruise indication, brake indication, turn indication, gear indication, mileage indication, real-time speed indication, kilometer/mile indication unit, battery power indication, fault code indication, start mode indication, single and dual drive indication, etc.
Function setting: After you press the power button three times in a row to enter the menu setting interface, the instrument will display P1, P2, P3, P4, P6, P8, PA, PB, and PC, which respectively represent:
P1 is the kilometer/mile selection setting;
P2 is the voltage level setting;
P3 is the wheel diameter setting;
P4 is the magnetic pole pair setting;
P5 is the cruise and no cruise selection setting;
P6 is the non-zero start and zero start selection setting;
P8 is the automatic sleep time setting;
PA is the start force setting;
PB is the brake force setting;
PC is the total mileage clearing 0 setting;
Speed limit mode: hold the brake handle and double-click the power button at the same time.
Packing list: User manual*1，tool*1，charger*1，bolts*4，handle lock*1
